Card found : S/N : F03C2EF2 , v0165
Chinese Miracle II  [MTK module] v 1.58

Operation : Read Flash [ v1.58 ]

1. Power Off Phone , Remove battery , Insert back
2. Insert USB cable. In some cases require hold BootKey ( '*' )

Wait for phone...
Phone found! [ 4 ]
Sync...
Sync Ok, read regs...
Inital regs read done
Boot Info :
BB_CPU_ID : 6261
BB_CPU_HW : CA02
BB_CPU_SW : 0001
BB_CPU_SB : 8000
BB_CPU_NM : [MediaTek] MT6261_S0000
BB_CPU_SN : 56C36E5600387427132B2CE457C961C3
BROM Protocol Version : 05
Setting...
Setting done , result code 0x000E
BROM stage done
Seek and prepare DownloadAgent
DownloadAgent matching HW Found!
DA verify and select done
Sending DA to target ...
DA_INFO   : 0xC0 , Ver : 3.2 , BBID : 0x8E
SOC_VERIFY : 0xC1
BOOT_STYLE : SF_FLASH_BOOT
NOR Flash IC initialized
[0] : FLASH_VEN : 0x0113 , [Winbond] SF_W25Q32JV
[0] : FLASH_DIE : 00EF 0070 0016 0000
[0] : FLASH_LEN : 0x00400000
SDS_INFO : 0x003FE000 , 0x00002000
INT_RAM : 0x0000D000
EXT_RAM : 0x00400000
Reading Flash Content now ...

Read Flash now
Read Ok , 4194304 bytes read
Check and collect compile info
File_Info   : FLYCOM61D_C202_B1818M_PCB01_gprs_MT2502_S00.MAUI_11C_W13_52_MP_V13.bin
FileVersion : MAUI.11C.W13.52.MP.V13
Saved to : C:\InfinityBox\CM2MTK\Read_out\FLYCOM61D_C202_B1818M_PCB01_gprs_MT2502_S00.MAUI_11C_W13_52_MP_V13.bin

Done!
Elapsed: 00:00:16
Reconnect Power/Cable!

Operation : Read Flash [ v1.58 ]

1. Power Off Phone , Remove battery , Insert back
2. Insert USB cable. In some cases require hold BootKey ( '*' )

Wait for phone...
Phone found! [ 4 ]
Sync...
Sync Ok, read regs...
Inital regs read done
Boot Info :
BB_CPU_ID : 6261
BB_CPU_HW : CA02
BB_CPU_SW : 0001
BB_CPU_SB : 8000
BB_CPU_NM : [MediaTek] MT6261_S0000
BB_CPU_SN : 56C36E5600387427132B2CE457C961C3
BROM Protocol Version : 05
Setting...
Setting done , result code 0x000E
BROM stage done
Seek and prepare DownloadAgent
DownloadAgent matching HW Found!
DA verify and select done
Sending DA to target ...
DA_INFO   : 0xC0 , Ver : 3.2 , BBID : 0x8E
SOC_VERIFY : 0xC1
BOOT_STYLE : SF_FLASH_BOOT
NOR Flash IC initialized
[0] : FLASH_VEN : 0x0113 , [Winbond] SF_W25Q32JV
[0] : FLASH_DIE : 00EF 0070 0016 0000
[0] : FLASH_LEN : 0x00400000
SDS_INFO : 0x003FE000 , 0x00002000
INT_RAM : 0x0000D000
EXT_RAM : 0x00400000
Reading Flash Content now ...

Read Flash now
Read Ok , 4194304 bytes read
Check and collect compile info
File_Info   : FLYCOM61D_C202_B1818M_PCB01_gprs_MT2502_S00.MAUI_11C_W13_52_MP_V13.bin
FileVersion : MAUI.11C.W13.52.MP.V13

[ScatCFG] : MT2502 / MAUI.11C.W13.52.MP.V13 / NOR , SF
Firmware saved to : C:\InfinityBox\CM2MTK\Read_out\FLYCOM61D_C202_B1818M_PCB01_gprs_MT2502_S00\

Done!
Elapsed: 00:00:18
Reconnect Power/Cable!
